💡How to use this tool: pick your containment type and size, then enter your cable mix on the left. Your fill percentage and compliance status update instantly on the right.
▭

Containment type & size

◯
Conduit
Circular
▭
Trunking
Rectangular
☰
Tray / basket
Open
⚹

Cable mix — enter quantities

Cable typeOD (mm)QtyTotal area
%

Fill guidance (editable)

Conduit max fill BICSI-aligned guidance
Trunking max fill BICSI-aligned guidance
Tray / basket max fill Open containment, more headroom
Fill vs guidance—

Cable area breakdown

CableODQtyArea
Total cable area0 mm²

Need a containment design check?

ACCL specifies conduit, trunking and tray sizing as part of every infrastructure design — free on all survey and quotation projects.

Book a free survey instead
0333 900 0101
Explore our other free calculators
Data cabling cost Wi-Fi installation CCTV installation Access control PoE budget
The editable fill percentages are practical planning defaults for telecommunications pathways, not universal statutory limits. Leaving headroom supports cable pulling, bend control, thermal performance and future additions. Conduit internal diameters and trunking/tray internal areas shown are typical figures for standard products — confirm against the specific manufacturer’s datasheet for tight or safety-critical runs. This is indicative guidance, not a substitute for a site-specific design check.

How this cable fill calculator works

Use the cable fill calculator to compare a mixed cable schedule with the usable cross-sectional area of conduit, trunking or cable tray. Select the containment type and dimensions, enter the quantity and outside diameter of each cable, and the result updates instantly.

The calculation uses the outside diameter of each circular cable to estimate its occupied area. Because cable diameters vary by manufacturer and product construction, confirm the figures against the selected cable datasheet before finalising a structured data cabling design.

The calculator supports copper data cables, coax and fibre, as well as custom cable types. This makes it useful for early route planning across office fit-outs, comms-room upgrades, security systems and fibre optic installations.

Important: the default fill percentages are editable planning values, not universal legal limits. Final containment sizing should follow the project specification, current installation standards, manufacturer data and the practical route conditions found during survey.

Why cable containment capacity matters

Overfilled conduit or trunking can increase pulling tension, compress cable bundles, make bend-radius control more difficult and leave no practical capacity for future additions. ACCL’s guide to common data cabling faults explains how overfilled containment can also contribute to damaged links and thermal problems on high-density PoE installations.

Containment should be selected around the complete cable schedule, route length, bends, draw-in points, segregation, fire stopping, manufacturer dimensions and future growth. Our office cabling service includes trunking, containment and above-ceiling or under-floor routing as part of the installation design.

For mixed copper and fibre routes, consider cable outside diameter, bend requirements and how the pathway will be accessed later. The cable category itself also affects diameter, shielding and bundle density, so review our comparison of Cat5e, Cat6, Cat6A, Cat7 and Cat8 cables when building the schedule.

The wider planning and installation principles for telecommunications pathways are covered by ISO/IEC 14763-2:2019 and, for cabling inside buildings, BS EN 50174-2:2018.

A calculation cannot confirm the actual route, internal product dimensions, existing services or installation access. ACCL’s free site survey checks these conditions before a containment design and fixed-price quotation are prepared.

Need the containment design checked?

Book a free ACCL site survey to confirm cable quantities, pathway dimensions, route constraints, future capacity and the correct conduit, trunking or tray specification.

Book Your Free Site Survey
`;const win = window.open('', '_blank'); if (!win) { const blob = new Blob([html], { type: 'text/html' }); const url = URL.createObjectURL(blob); const a = document.createElement('a'); a.href = url; a.download = 'ACCL-Fill-Report-' + ref + '.html'; a.click(); URL.revokeObjectURL(url); return; } win.document.open(); win.document.write(html); win.document.close(); win.addEventListener('load', () => { setTimeout(() => { win.focus(); win.print(); }, 600); }); }// Pre-fill a sample cable mix so the preview shows real results // (2x Cat6A + 1x Cat6 in a 25mm conduit ≈ 34.5% fill — just under the // 40% guidance, illustrating the "approaching limit" amber state) setTimeout(() => { const sample = {1: 1, 2: 2}; Object.entries(sample).forEach(([i,q]) => { const input = document.querySelectorAll('.qty-inp')[i]; if (input) { input.value = q; setQty(+i, q); } }); }, 0);
This field is for validation purposes and should be left unchanged.

How this structured cabling cost calculator works

This structured cabling cost calculator gives facilities managers, IT teams and project leads an early estimate for a commercial installation. It uses the number of data points, cable category, building type, floors served, additional infrastructure and required delivery timescale to provide an indicative project range.

It is designed for initial budgeting, business-case planning and early conversations around office moves, refurbishments, technology upgrades and expansion projects. It is not a fixed quotation.

For detailed UK pricing guidance, including cost-per-point benchmarks, specification considerations and quote-comparison advice, read our Structured Cabling Cost UK guide. That guide covers the broader research stage, while this calculator is designed to help you estimate a live project.

What can affect the final project cost?

The number of outlets is only one part of the scope. Final pricing can also be affected by the building layout, cable routes, containment, riser access, floor voids, working hours, occupied areas and programme constraints.

Additional infrastructure can also change the project scope. This may include fibre backbone links between floors or cabinets, Wi-Fi access point cabling, CCTV infrastructure, access control cabling and comms cabinet upgrades.

The calculator provides a sensible starting point. ACCL’s free site survey then confirms the practical details, including cable routes, cabinet locations, containment requirements, access restrictions, testing requirements and the most appropriate installation approach.

For a more detailed planning checklist, see our Cabling Project Cost Factors and Budget Checklist.

Choosing Cat6 or Cat6A

Cat6 is suitable for many standard office networks and lower-demand environments. Cat6A is typically the stronger long-term option where a business expects higher bandwidth, denser Wi-Fi, increased PoE demand, 10Gb capability or future expansion.

The right choice depends on the devices, network requirements, building layout and expected lifecycle of the installation. ACCL can advise on the appropriate cable category as part of the survey and design process.

For further guidance, read When to Upgrade Your Office to Cat6A.

From indicative estimate to formal quotation

Every ACCL installation is planned around the building, programme and technical requirements of the project. Following a free site survey, we can provide a defined scope, installation approach and formal quotation.

Projects can include structured data cabling, fibre backbone links, Wi-Fi access point cabling, CCTV infrastructure, access control cabling, comms cabinets, testing, certification and handover documentation as one coordinated delivery.

Explore our Structured Data Cabling service to understand the full ACCL delivery process, from survey and design through to installation, Fluke DSX-8000 certification and documentation.

ACCL designs and installs structured cabling systems with reference to recognised installation and quality-assurance standards, including BS EN 50174-1. Our testing approach uses Fluke Networks DSX CableAnalyzer equipment to certify installed copper cabling systems.

Ready to validate your estimate?

Book a free ACCL site survey to turn your indicative range into a defined scope, practical installation plan and formal quotation.

Book Your Free Site Survey

Get in touch today

Have a no-obligation chat with one of our data cabling experts, who can recommend a solution to suit your requirements and budget.

0333 900 0101 sales@network-data-cabling.co.uk Contact us

Frequently Asked Questions – (FAQs)

Q. What is cable fill?

Cable fill is the proportion of the usable internal area of a conduit, trunking or cable tray that is occupied by cables. Leaving sufficient unused capacity helps with installation, cable management and future additions.

Q. How does the cable fill calculator work?

The calculator uses the outside diameter and quantity of each cable to estimate its cross-sectional area. It then compares the combined cable area with the internal area of the selected containment.

Q. What cable fill percentage should I use?

There is no single percentage that applies to every pathway or project. The calculator provides editable planning values, but the final allowance should follow the project specification, current installation standards, manufacturer guidance and actual site conditions.

Q. Why should containment have spare capacity?

Spare capacity makes cables easier to install and maintain, provides room for future additions and reduces the risk of excessive pulling pressure, compressed bundles and poor thermal performance.

Q. Can I calculate a mixture of different cable types?

Yes. You can combine Cat5e, Cat6, Cat6A, Cat7, fibre and coax cables or add a custom cable using its measured outside diameter.

Q. Why is the cable outside diameter important?

Cables within the same category can have different outside diameters because of conductor size, shielding, jacket construction and manufacturer design. Using the selected product’s actual diameter produces a more reliable result.

Q. Can overfilled containment affect PoE cabling?

Dense cable bundles can retain more heat, particularly where multiple cables carry higher PoE loads. Cable category, conductor size, bundle arrangement, ambient temperature and containment design should all be considered.

Q. Do I still need a site survey?

Yes. The calculator cannot assess bends, draw-in points, segregation, fire stopping, existing services, route access or the exact internal dimensions of the selected containment. A site survey is required before the final design is confirmed.
